| Diameter (mm) | 218 |
| Inner Diameter (mm) | 143 |
| Length (mm) | 515 |
| Media | Ultra-Web Flame Retardant |
| Media Weight (g/m²) | 260 |
| Area (m²) | 3 |
| Unit Family | Quick Fix 3 |
| Pitch Diameter (mm) | 267 |
| Top End Cap Design | Open with 3 Hooks |
| Bottom End Cap Design | Closed |
| Earthed | No |
| Flame Retardant | Yes |
| Outer Liner | Yes |
| End Cap/Liner Material | Polyurethane |
| Gasket Position | Above Top End Cap |
| Pleath Height (mm) | 49 |
| Number of Pleats | 139 |
| Max. Temp (°C) | 60 |
| Volume (m³) | 0.07484 |
| Weight (kg) | 3.17 |
