| Diameter (mm) | 202 |
| Inner Diameter (mm) | 91 |
| Length (mm) | 406 |
| Media | #REF! |
| Media Weight (g/m²) | 114 |
| Area (m²) | 5.5 |
| Unit Family | TD small |
| Bottom End Cap Design | Closed with hole 13.5 mm |
| Earthed | Yes |
| Flame Retardant | No |
| Top End Cap Design | Open |
| Outer Liner | Yes |
| Gasket Position | Above Top End Cap |
| End Cap/Liner Material | Galvanized Steel |
| Pleath Height (mm) | 51 |
| Number of Pleats | 141 |
| Max. Temp (°C) | 65 |
| Volume (m³) | 0.01896 |
| Weight (kg) | 1.71 |
